Behringer ECM8000 Measurement Condenser Microphone

Behringer ECM8000 Measurement Condenser Microphone

Behringer ECM8000 is an omnidirectional measurement condenser microphone for suitable acoustic-analysis systems. Its balanced audio route requires a compatible microphone input and phantom power.

Why Choose Behringer ECM8000?

ECM8000 is intended to capture the room and speaker response for an analyser or suitable measurement workflow. Behringer documents a 15Hz–20kHz response and +15V to +48V phantom-power requirement. An omnidirectional pattern differs from a close vocal cardioid microphone because it samples sound from around the capsule. Meaningful results depend on measurement position, levels, software and the complete input chain. An individual microphone calibration file is not established by this listing, so do not represent every supplied unit as individually certified or assume software and a recording interface are included.

Key Features

• Measurement role: acoustic and speaker-response capture.
• Omnidirectional pickup: room-oriented sampling pattern.
• Condenser operation: compatible phantom power needed.
• System workflow: analyser or suitable measurement software.

Best Suited For

Checking loudspeaker and room response through a compatible acoustic-analysis workflow. Choose measurement positions around the listening area and the purpose of the test. A measurement microphone supplies a signal; the analyser, calibration approach, audio interface and test procedure determine how that signal becomes useful response information.

Setup and Connection Guide

Mount the microphone securely and connect its balanced output to a suitable mic input. Enable the documented phantom voltage, keep input gain and playback levels conservative and select the input in the analysis software. Establish a repeatable microphone position and use the supported calibration procedure before interpreting results. Run a controlled test signal and check for overload or background interference. Compare several relevant positions when evaluating the room rather than treating one point as the whole audience area. Save the measurement conditions so later changes can be compared fairly.

Frequently Asked Questions

Is an individual calibration file included for every ECM8000?

That is not established by this listing. Check the actual unit and package if individually calibrated response data is required. The model’s published response is different from a serial-number-specific calibration certificate.

Can this microphone calculate an equaliser curve by itself?

No. It provides the acoustic measurement signal. Appropriate analysis software or hardware interprets the response, and any equaliser or room correction must be applied by compatible downstream equipment.

Will one measurement position describe the whole room?

No. Response changes with position, speaker placement and room reflections. Use a measurement plan suited to the task and compare relevant seats. Confirm test levels and calibration before deciding which system changes are justified.

Technical Specifications

Explore Related Equipment

Explore Behringer U-PHORIA UMC22 USB Audio Interface and compare its role, connections and compatibility with the setup you are planning.
