The DPA DAD6034 Adapter connects a DPA microphone with a MicroDot connector to a locking 3.5 mm input, and the DPA DAD6034 Adapter is the link between DPA miniature microphones and Sennheiser wireless bodypacks. Where the DAD9034 serves MicroLock microphones, the DAD6034 serves MicroDot microphones, so a 4060 or 6060 with a MicroDot lead can plug straight into a Sennheiser Evolution, G2 or G3 bodypack.
Why Choose DPA DAD6034 Adapter?
Connector families are easy to confuse and expensive to get wrong, and the DAD6034 exists precisely because MicroDot and MicroLock are different terminations. The locking 3.5 mm plug stays seated in the bodypack during performance, which matters when a performer moves, dances or changes costume, and the passive design adds nothing to the signal path. For a sound team that already owns MicroDot lavaliers and Sennheiser wireless, this small adapter saves replacing either side.
Key Features
MicroDot to locking 3.5 mm: Adapts DPA MicroDot microphones to locking mini-jack bodypack inputs.
Sennheiser compatibility: Fits Sennheiser Evolution, G2 and G3 series bodypacks.
Locking connector: The locking mini-jack stays seated during performance.
Passive design: No battery or extra electronics in the signal path.
Distinct from DAD9034: DAD6034 is for MicroDot microphones; DAD9034 is for MicroLock microphones.
System flexibility: Lets MicroDot lavaliers serve Sennheiser wireless systems.
Best Suited For
The DPA DAD6034 Adapter suits theatre, broadcast and event sound engineers who run Sennheiser wireless and own DPA MicroDot microphones such as the 4060 and 6060 families. It is an adapter, not a microphone, and it fits MicroDot microphones only: MicroLock microphones need the DAD9034 instead. It costs far less than replacing a microphone or a bodypack, and it keeps a proven lavalier in service when the wireless system changes.
Setup and Connection Guide
Plug the microphone’s MicroDot connector into the DPA DAD6034 Adapter and push the locking 3.5 mm plug into the bodypack transmitter until it locks. Check the bodypack’s input gain for the microphone, since DPA lavaliers are sensitive, and confirm the lock is engaged before the performer goes on. Note that the sheet parent group for this row reads as a microphone, but the DAD6034 is an adapter, and it is listed here under adapters. Keep the adapter with the MicroDot microphone it belongs to, and label the bodypack side clearly, since MicroDot and MicroLock adapters look almost identical and swapping them is the most common cause of a silent channel on show day.
Frequently Asked Questions
Which transmitters does the DAD6034 fit?
Sennheiser bodypacks with a locking 3.5 mm input, including the Evolution, G2 and G3 series.
What is the difference from the DAD9034?
The DAD6034 takes a MicroDot microphone input, while the DAD9034 takes a MicroLock microphone input. The output side is the same locking 3.5 mm plug, so the two adapters are not interchangeable.
Does the adapter need power?
No. It is passive and passes the bodypack’s bias power to the microphone.
Technical Specifications
Brand
DPA
Model
DAD6034
Type
MicroDot to locking 3.5 mm adapter
Input connector
MicroDot
Output connector
3.5 mm locking mini-jack
Compatible transmitters
Sennheiser Evolution / G2 / G3 series bodypacks
Design
Passive, no battery required
Note
Sheet parent group reads MICROPHONE; DAD6034 is an adapter
Sheet parent group reads MICROPHONE; DAD6034 is an adapter
Model / SKU
DPA-DAD6034
Category
Adaptor
Condition
Brand new, sealed box
Warranty
Official manufacturer warranty (India)
GST invoice
Yes, input credit available
