H&Y Revoring II Variable ND Filter (67–82mm)

H&Y Revoring II Variable ND Filter (67–82mm)

The H&Y Revoring II, in this 67–82mm size, solves a problem every photographer and filmmaker with more than one lens recognises: filters are sold in fixed thread sizes, so a variable ND bought for one lens does not fit the next, and the bag fills with step-up rings and duplicate filters. The Revoring replaces all of that with a single filter whose mounting ring adjusts to any lens thread between 67mm and 82mm. Self-retracting blades with threaded ends expand or contract to the lens, overlap to block light leaks, and lock the filter in place.

This second-generation model combines a variable neutral density filter and a circular polarizer in one unit. The variable ND spans ND3 to ND1000, which is 1.5 to 10 stops of light reduction, adjusted by rotating the outer ring against a hard stop at the maximum setting. The polarizer rotates independently, with its own locking control, so exposure and polarization can be set separately and then held.

Key features

• One filter for many lenses: The self-adjusting Revoring mount fits every lens thread from 67mm to 82mm, replacing multiple fixed-size filters and step-up rings.
• ND3 to ND1000 variable range: 1.5 to 10 stops of continuously variable light reduction, with a hard stop at MAX so the ring cannot travel past the usable range.
• Combined variable ND and circular polarizer: Exposure control and polarization in a single filter, with the polarizer using Japanese Nitto polarizing film rated at up to 99.9 percent polarization efficiency.
• Dual locking knobs: Separate locks for the variable ND and the polarizer let each setting be fixed independently once dialled in, a Mark II improvement for video work.
• German Schott B270 glass: Optical glass with nine-layer nano coatings on both sides for reduced reflections and flare, plus anti-fingerprint and water-repellent surface treatment.
• Architectural-grade aluminium frame: A lightweight, anodised frame that resists corrosion outdoors, with guide pins and focal length markings to repeat settings between lenses.
• RevoSwift system compatibility: Works with H&Y’s RevoSwift matte box and 100mm magnetic filter system through the Bridge Ring, extending the same mount into a larger filter workflow.

How the Revoring mount works

The mount is the invention here. Instead of a fixed thread, a set of retractable blades forms a variable-diameter threaded interface: twist and press the filter onto the lens and the blades settle into the thread, anywhere in the 67 to 82mm span. The threaded ends overlap, which removes the gaps where stray light can enter behind a filter and fog a long exposure. A safety locking arrangement on the Mark II holds the fit securely during handling, so the filter stays put when the camera is carried between positions. Markings between MIN and MAX on the ND ring relate density to focal length, because the stops achieved at a given ring position vary with the lens in use.

Exposure and polarization control

For video, the variable ND is what allows a 180-degree shutter angle to be held in bright daylight at a wide aperture: the density is trimmed continuously until the exposure is right, rather than in the fixed steps of a filter set. For stills, the same range opens up wide-aperture portraiture in full sun and long-exposure effects such as blurred water and streaked clouds. The circular polarizer works alongside it, reducing reflections from glass and water, deepening sky tones and increasing colour saturation. Because the two controls lock independently on the Mark II, a polarizer angle found for a scene is not disturbed while the ND is adjusted for a cloud passing overhead.

Optical quality and handling

The filter glass is German Schott B270, coated with nine layers on both sides combining anti-reflective and nano-coating technology to maintain light transmission and control flare, with a hydrophobic, anti-fingerprint finish that is easier to keep clean in the field. The frame is architectural-grade aluminium with a matte black anodised finish, and the 67–82mm Mark II unit weighs about 145 grams, so it adds little to a lens that already takes an 82mm filter. The polarizer’s Nitto film is the component behind the published 99.9 percent polarization efficiency figure.

Where it fits

The Revoring II suits hybrid shooters who move between lenses during a wedding, travel shoot or production day and cannot pause to swap rings, landscape photographers who want one ND and polarizer set for a whole lens kit, and filmmakers building a compact rig around the RevoSwift matte box ecosystem. Any lens with a front thread between 67mm and 82mm is covered by this single unit.

One adjustable mount, ten stops of variable density, an independent polarizer and optical glass from Schott: the Revoring II in the 67–82mm size turns a bag of thread-specific filters into a single tool that is already fitted to whichever lens comes out of the bag.
