Milestone MP-DA4UHD-H2 HDMI Distribution Amplifier 1×4
SKU MILSTONE-HDMI-DISTRIBUTOR-MP-DA4UHD-H2
Original price was: ₹18,990.₹16,990Current price is: ₹16,990. Save ₹2,000 (11%)
- Price includes GST, invoice provided
- Dispatched the same day
- Cash on delivery up to ₹45,000
- Money-back if it arrives damaged
The Milestone MP-DA4UHD-H2 is a 1×4 HDMI distribution amplifier that mirrors one UHD HDMI source to four displays at the same time.
In stock· Dispatched the same day
100% secure checkout · Pay your way
100% genuine, authorised stock
Official Indian warranty
Same-day dispatch · 7-day returns
Need advice?
Product highlights
- Configuration1 In 4 Out
- TypeHDMI Distribution Amplifier
- HDMI Inputs1 x HDMI, Type-A female
- HDMI Outputs4 x HDMI, Type-A female
- Max Output ResolutionUp to 4Kx2K at 60Hz, 4:4:4, 8-bit
- Max Input ResolutionUp to 4Kx2K at 60Hz, 4:4:4, 8-bit
Description
Milestone MP-DA4UHD-H2 HDMI Distribution Amplifier 1×4
The Milestone Pro MP-DA4UHD-H2 is a 1×4 HDMI distribution amplifier that takes a single HDMI source and sends it to four displays at the same time, in full quality. It is an HDMI 2.0 device with 18 Gbps bandwidth, supporting resolutions up to 4Kx2K at 60Hz with 4:4:4 chroma and 8-bit colour, and it is compliant with HDCP 2.2 and 1.4, so protected content from modern players, consoles and set-top boxes passes without issue.
Because every output carries the same signal, the MP-DA4UHD-H2 is the clean way to run one source to multiple screens – a media player feeding four TVs in a sports bar, a presentation shown on screens across a boardroom, or a demo loop running on a row of displays in a showroom.
Key Features
- 1 HDMI input distributed to 4 HDMI outputs simultaneously
- HDMI 2.0, 18 Gbps – up to 4K at 60Hz 4:4:4 8-bit on every output
- HDCP 2.2 and 1.4 compliant, CEC supported
- Built-in downscaling for systems mixing 4K and 1080p displays
- EDID management via 4-pin DIP switch, plus HDCP mode selection
- Micro-USB port for firmware upgrades
- Compact metal chassis (142 x 17.6 x 70.4 mm) with mounting ears included
Why downscaling and EDID management matter
In a multi-display system the source normally negotiates one resolution for everything, so a single 1080p screen in a set of 4K TVs can drag the whole system down to 1080p. The down-scale function in the MP-DA4UHD-H2 lets higher-capability displays keep their native 4K signal while lower-resolution outputs are scaled appropriately. The DIP-switch EDID management works alongside this: instead of relying on whichever display answers first, the installer can fix the EDID the source sees, which prevents resolution flicker, blank screens and HDCP handshake problems when displays are switched or cables are changed.
Where it is used
Typical applications include digital signage, sports bars and restaurants, classrooms and training rooms, control rooms, retail showrooms and home theatres with a second zone display. The unit supports HDMI cable runs up to 5 m at 4K 60Hz 4:4:4 and up to 20 m at 1080p, runs from the included 5V DC adapter, and shows power, input and per-output status on front-panel LEDs so an installer can see the signal state at a glance.
Complete technical data – resolutions, bandwidth, cable lengths, power and dimensions – is given in the specifications table on this page.
Additional Information
Specifications
| Configuration | 1 In 4 Out |
|---|---|
| Type | HDMI Distribution Amplifier |
| HDMI Inputs | 1 x HDMI, Type-A female |
| HDMI Outputs | 4 x HDMI, Type-A female |
| Max Output Resolution | Up to 4Kx2K at 60Hz, 4:4:4, 8-bit |
| Max Input Resolution | Up to 4Kx2K at 60Hz, 4:4:4, 8-bit |
| HDMI Standard | HDMI 2.0 |
| HDCP Compliance | HDCP 2.2 and 1.4 |
| Bandwidth | 18 Gbps |
| CEC | Supported |
| Downscaling | Yes - per-output down-scale for mixed-resolution displays |
| EDID Management | 4-pin DIP switch for EDID and HDCP mode selection |
| Firmware Port | Micro-USB port for firmware upgrade |
| HDMI Cable Length | 4K at 60Hz 4:4:4 up to 5 m, 4K 4:2:0 up to 15 m, 1080p up to 20 m |
| Operating Temperature | -10 to +55 degrees C |
| Storage Temperature | -25 to +70 degrees C |
| Relative Humidity | 10% - 90% |
| Power Supply | 100-240V AC input, 5V DC 1A output adapter (included) |
| LED Indicators | Power, input and per-output status LEDs |
| Power Consumption | 2.5W max |
| Model / SKU | MILSTONE-HDMI-DISTRIBUTOR-MP-DA4UHD-H2 |
| Category | Connector |
| Condition | Brand new, sealed box |
| Warranty | Official manufacturer warranty (India) |
| GST invoice | Yes, input credit available |
