Blackmagic Design ATEM Mini Extreme ISO Live Production Switcher
Blackmagic Design ATEM Mini Extreme ISO Live Production Switcher
ATEM Mini Extreme ISO is a live production switcher with 8 x HDMI inputs for a compatible HD camera and programme workflow. Why Choose ATEM Mini Extreme ISO? This listing identifies the original ATEM Mini Extreme ISO, not the newer G2. Its ISO workflow records the eight input feeds and switched programme for later editing. Keep the original hardware generation distinct when planning recording media and audio connections; the G2’s CFexpress, Thunderbolt and 10G storage features belong to a different hardware generation. Key Features – 8 HDMI video inputs. – Separate ISO input and programme recordings. – 2 HDMI output arrangement. – Original Extreme ISO generation. Best Suited For
Combining compatible cameras, computers and other sources into a live programme for events, teaching, interviews or streaming. Plan the input connector type and production resolution before counting cameras. An HDMI source and an SDI source may need a suitable converter to join the same system. Recording the finished programme differs from recording individual camera feeds, so select an ISO version when separate input files are required for later editing. Setup and Connection Guide
Connect supported video sources and a monitoring display with the equipment safely positioned and adequately ventilated. Set a compatible production standard and check every camera and computer input before going live. Configure audio levels, microphone or line-input settings and monitoring through the supported control software. For streaming, establish a stable network connection and enter the destination settings securely. For recording, use supported media with sufficient capacity and sustained write performance. Make a short test recording, replay it and verify synchronisation and sound. Label camera inputs and rehearse transitions. Keep a local operational plan for network interruptions; an internet connection and platform account are separate requirements. Frequently Asked Questions
Is this the same hardware as Extreme ISO G2? No. This is the original Extreme ISO reference. Select the separately listed G2 when that generation’s additional hardware connections and media facilities are required. Does an ISO version record the same thing as programme-only recording? No. ISO recording adds separate input recordings for editing, subject to the specific model and media requirements. Programme recording saves the live switched result. Does a USB-C connector automatically mean Thunderbolt or 4K video support? No. Connector shape does not establish the protocol or supported picture format. Use the exact model specification for each port and production mode. Technical Specifications Specification
Detail Model
ATEM Mini Extreme ISO Primary video inputs
8 x HDMI Production standard
HD up to 1080p60 Recording reference
8 clean input recordings plus switched programme Software
Compatible ATEM Software Control Media and cables
Confirm actual package and supported specifications Explore Related Equipment
Compare Blackmagic Design ATEM Mini Extreme ISO G2 Live Production Switcher when checking the model, connections and installation requirements for your system.
Additional Information
Specifications
Video Inputs
8 x HDMI Type A, 10-bit HD, standards converted and re-synced on every input
ISO Recording
Records 9 H.264 streams, all 8 ISO inputs plus program, with a DaVinci Resolve project file
Multiview
Up to 16 views, configurable
HDMI Outputs
2 HDMI program outputs
Streaming
Direct RTMP streaming over Ethernet or a tethered mobile connection over USB-C
Audio Mixer
11-input x 2-channel Fairlight mixer with compressor, gate, limiter and 6-band parametric EQ
Brand
Blackmagic Design
Model
ATEM Mini Extreme ISO
Upstream Keyers
4
Downstream Keyers
2
Chroma Keyers
Up to 4 ATEM Advanced Chroma Keyers
Media Players
2 media players, media pool holds 20 RGBA stills
Audio Inputs
2 x 3.5 mm stereo mini jack
Audio Output
1 x 3.5 mm stereo mini jack headphone output
Computer Interface
2 x USB Type-C 3.1 Gen 1 for external drive recording, webcam output, software control and updates
Ethernet
10/100/1000 BaseT for streaming, software control and panel connection
Dimensions
370 x 136.6 x 39.6 mm
Weight
1.23 kg
Model / SKU
BMD-ATEM-MINI-EXTREME-ISO
Category
Professional Video
Condition
Brand new, sealed box
Warranty
Official manufacturer warranty (India)
GST invoice
Yes, input credit available
